60 years of experience with evolving technology has produced the HANDY H29E-A!
The H29E-A model is suitable for washing cups, glasses, saucers and dishes (using the appropriate rack) with a clearance of up to 295 mm. The drain pump option allows you to handle the drain automatically and perform a partial replacement of clean water at each wash cycle.
This model is ETL and ETL Sanitation certified as it meets the requirements of the NSF/ANSI 3 rule. The washing cycles have been specifically designed to make the dishwasher compliant with the NSF hygienic safety standards, recognized by the American National Standards Institute (ANSI).
The simple electronic board control system makes it possible to set and control the rinsing, draining times, temperatures and the relevant Thermostops, crucial for ensuring excellent final results. With the control panel, you can choose one of its 4 washing cycles and one automatic drain cycle (with installed drain pump), easily view on the display the tank and boiler temperature, the messages of the Self-Diagnosis system and the Scheduled Maintenance warning. The smart Start button changes colour to always keep you up-to-date on the dishwasher status with the greatest ease.
The electronic control allows you to manage various parameters to give you an absolute customization level and the continuous self-diagnosis allows you to minimize machine downtime, suggesting some operations that need to be verified.
The self-cleaning cycle at the end of the day cleans the wash tank and empties the hot water from the boiler, preventing limestone from building up inside.
The standard double peristaltic electric rinse-aid and detergent dispenser ensures the best result from each wash cycle with great savings thanks to the precise dosage managed by the electronic card; whereas, the moulded washing and rinsing arms ensure great reliability and durability.
The Thermo-stop function checks that washing and rinsing begin only when the desired temperature is reached.
The bodywork is made entirely of AISI 304 steel and has been designed with all of the components in the front for easy technical assistance.
Ecoclean: Water control system for partial clean water refill in every wash cycle.
Stainless Steel: Adjustable rotation speed rinse arms, integral tank filter, with detergent injector welded to the tank.
ETL Sanitation: Programmed to guarantee the perfect sanitation result at high rinse temperatures.
LCD Controls: Simple digital control panel with digital temperature display for intuitive and user-friendly operation.
*NOTE: Dishwasher Stand , the 3-Tier Glass Rack and the 4-Tier Glass Rack are each sold separately.
- Control panel with LCD display
- ETL Sanitation to guarantee a powerful wash and sanitization with a high rinse temperature
- EWC System, electronic control with 4 individual programmable cycles
- Built in drain pump with Ecology Care system for partial refilling of clean water in every washing cycle
- Vacuum breaker valve
- Integral stainless steel tank filter + New filtering group for suction and drain
- Racks supplied: 1 dish basket, 1 glass basket, and 2 cutlery trays
- Adjustable 3L/hour detergent dispenser
- Adjustable 0.3L/hour rinse-aid dispenser
- 48 racks/hour or approximately 42 racks/hour in accordance with NSF standards
- 1 Year parts and labour warranty
This item is not warehoused by Williams Food Equipment, processing times, delivery times and availability may vary. If this item is required by a certain date, please contact Williams Food Equipment before ordering to ensure delivery times can be met. It may not be possible to cancel this item once ordered and may be non-returnable. If returnable, this item may be subject to restocking charges and return delivery fees outside of the control of Williams Food Equipment. If you have any questions about this item or the terms above, please call us at 1-888-334-3233 or email us at [email protected].
| Product Specifications | |
|---|---|
| Brand | Thesis |
| Model | H29E-A |
| Type | Dishwashers |
| Controls | Digital |
| Rack Size | 14" x 14" |
| Door Clearance | 12.2" / 310 mm Height |
| Wash Pump | 1/3 HP |
| Tank Heating Element | 2.6kW, capacity: 4.5gal (17L) |
| Booster Heating Element | 2.5kW, capacity: 0.9gal (3.2L) |
| Power Requirements | 2.79kW, 208/220V 50/60Hz, 15A 1PH |
| Hot Water Requirements | ½ GPC (2.6LPC) 125°F (55°C), will operate with cold water at reduced capacity |
| Water Line Requirements | ¾" (or ½" with ¾" NPT terminal) hose supplied |
| Water Pressure Requirements | 30–45psi (2–3bar) |
| Drain Line | 1" (25mm) connection hose supplied |
| Dimensions - WDH | 18.5" x 21.75" x 38" / 470 x 555 x 710 mm |
| Product Weight | 86 lbs / 39 kgs |
| Certifications | cETLus / ETL Sanitation / NSF |
| Warranty | 1 Year |
