The Star Ultra-Max 48" Electric Griddle is engineered to deliver exceptional cooking performance, precise temperature control, and long-lasting durability in demanding commercial kitchens. Featuring a premium 1" thick chrome-plated griddle surface, this countertop unit provides superior heat retention, excellent heat distribution, and a smooth cooking surface that promotes easy product release and simplified cleanup.
Manufactured in the USA, the Ultra-Max series is built with a corrosion-resistant stainless steel body designed to withstand years of daily use. The 48" cooking surface is divided into four independently controlled 12" cooking zones, each powered by a dedicated 4.35 kW heating element. This design allows operators to cook different menu items simultaneously while maintaining precise temperature control in each section.
Advanced electric snap-action thermostats utilize sensors embedded just 3/16" below the cooking surface every 12 inches, providing fast response times and accurate temperature regulation. Each section is independently adjustable from 150°F to 450°F (66°C to 232°C), making the griddle ideal for everything from delicate breakfast items to high-temperature searing and grilling applications.
Designed with operator convenience in mind, the griddle features a 3.5" grease trough and removable grease drawer for efficient grease management and simplified cleanup. Large 5.5" rear and side splash guards help contain grease and food debris, keeping surrounding work areas cleaner. The unit is supplied with four adjustable 4" legs that provide stability and installation flexibility on countertops.
Built for reliability and performance, the Star Ultra-Max 48" Electric Griddle is ready for hard-wire electrical installation on 208V service and is backed by a 2-year manufacturer's warranty, making it an excellent choice for restaurants, diners, cafeterias, and other high-volume foodservice operations.
- 48" electric countertop griddle
- Premium 1" thick chrome-plated griddle surface
- Four independently controlled 12" cooking zones
- Electric snap-action thermostats for precise temperature control
- Thermostat sensors embedded 3/16" below the cooking surface
- Temperature range: 150°F to 450°F (66°C to 232°C)
- Four 4.35 kW heating elements (17.4 kW total)
- Corrosion-resistant stainless steel construction
- 5.5" rear and side splash guards
- 3.5" grease trough with removable grease drawer
- Adjustable 4" legs included
- Ready for hard-wire 208V electrical connection
- Made in the USA
- 2-year manufacturer's warranty
| Product Specifications | |
|---|---|
| Brand | Star |
| Series | Ultra-Max |
| Type | Griddles |
| Voltage | 208V |
| Controls | Mechanical Snap-Action |
| Plate Material | Chrome |
| Temperature Range | 150°F - 450°F / 66°C - 232°C |
| # of Heating Sections | 4 |
| kW per Heating Section | 4.35 |
| Total kW | 17.4 |
| # of Grease Drawers | 1 |
| Plate Thickness | 1" / 25 mm |
| Plate Depth | 24" |
| Dimensions - HWD | 18" x 48" x 33.6" / 457 x 1220 x 853 mm |
| Product Weight | 440 lbs / 199.6 kgs |
| Certifications | cULus / UL EPH |
| Country of Origin | USA |
| Warranty | 2 Years |
