The Beverage-Air UCR72AHC is a 72" mobile undercounter refrigerator designed to deliver reliable cold storage with the durability and flexibility required in busy commercial kitchens. With a generous 17.88 cu. ft. capacity, it features a stainless steel front, sides, top, doors, and grille, paired with a corrosion-resistant aluminum interior for long-lasting performance and easy cleaning. A 1/2" thick sub-top adds strength beneath the work surface, making it well suited for prep areas, while full electronic controls and a standard interior thermometer allow for precise temperature monitoring.
This unit is equipped with three self-closing solid swing doors that include a 120° stay-open feature for efficient loading and unloading. Magnetic door gaskets ensure a tight seal, helping maintain consistent internal temperatures. Mobility is built in with 6" casters, two of which include brakes, allowing the refrigerator to be easily repositioned as kitchen layouts change. Inside, six epoxy-coated wire shelves provide flexible organization, and the field-reversible doors add installation versatility.
The refrigeration system uses environmentally friendly R290 refrigerant and meets all CARB, SNAP, and DOE requirements. An adaptive defrost system and epoxy-coated evaporator coil work together to ensure efficient operation and long-term reliability, maintaining product temperatures between 36°F and 38°F for safe, consistent food storage.
CABINET CONSTRUCTION
- Stainless steel front, sides, top, doors and grille (galvanized back & bottom)
- Interior liner is made of corrosion resistant aluminum
- Full electronic control
- Undercounter features a 1/2" thick sub-top
- Interior thermometer
- Self-closing door with 120° stay-open feature on cartridge style hinges
- Magnetic gasket attached to each door for positive seal
- 6" Casters, two (2) with brakes standard
- Six (6) epoxy-coated steel wire shelves
- Field-reversible door (hinge kit not included)
REFRIGERATION SYSTEM
- Uses environmentally friendly, energy efficient R290 refrigerant, and meets all regulatory requirements for CARB, SNAP, DOE & more
- Adaptive defrost
- Epoxy coated evaporator coil
- Refrigerators capable of maintaining product temperature between 36°F and 38°F
This item is not warehoused by Williams Food Equipment, processing times, delivery times and availability may vary. If this item is required by a certain date, please contact Williams Food Equipment before ordering to ensure delivery times can be met. It may not be possible to cancel this item once ordered and may be non-returnable. If returnable, this item may be subject to restocking charges and return delivery fees outside of the control of Williams Food Equipment. If you have any questions about this item or the terms above, please call us at 1-888-334-3233 or email us at commercial@williamsfoodequipment.com.
| Product Specifications | |
|---|---|
| Brand | Beverage Air |
| Model | UCR72AHC |
| Type | Refrigerators - Undercounter |
| Color | Stainless |
| Capacity | 17.88 cu. ft. |
| # of Doors | 3 |
| Door Type | Hinged / Solid |
| Door Locks Included | No |
| Self Closing Door | Yes |
| Temperature Control | Electronic |
| Temperature Range | 36 to 38°F |
| Defrost | Adaptive |
| # of Shelves | 6 |
| Casters | 6" |
| Refrigerant | R290 |
| Material | Stainless Steel / Aluminum |
| Electrical | 115V / 60Hz / 1Ph |
| Amps | 3.0 |
| Horsepower | 1/5 |
| Plug | NEMA 5-15P |
| Cord Length | 8' |
| Interior Dimensions - WDH | 68" x 15-3/8" x 23" |
| Depth w/ Doors Open | 52.25" |
| Door Openings | 19.5" x 21-5/8" |
| Dimensions - WDH | 72" x 32" x 34-5/8" |
| Certifications | cULus / UL EPH / UL Sanitation |
| Warranty | 7 Years |
| Country of Origin | USA |
