Patented FivePass Heat Transfer System distributes heat uniformly within cooking oil for fast recovery; enabling the fryer to cook up to 14% more lbs./hr. than competitive fryers.
The SoftStart Ignition System heats oil quickly while using half the BTUs at startup, resulting in extension of oil life. The trouble-free adjustable casters feature 2 swivel non-locking and 2 swivel locking casters for easy mobility.
Programmable computer controls with digital character display. This unit features 10 menu timers display product name and cook times and offline programming of menu items uploaded through USB interface, software is included. It has accurate temperature control 200-390°F with digital display, fast recovery and cook with compensating time or actual time. Enjoy the electronic ignition and digital temperatures: Fahrenheit or Celsius with three melt modes.
This unit is equipped with a built-in filter system. The filter vessel is constructed of 18 gauge stainless steel with a 1/3 HP motor/pump that circulates hot frying compound at the rate of 8 gallons per minute. The system is activated by a one-touch push-button switch and has a standard mesh filter screen.
- Filter system
- Tank capacity: 45-50 lbs each
- Digital display in Fahrenheit or Celsius
- Drain valve interlock switch – turns off gas burners automatically when draining oil
- 6" Casters adjustable - 2 locking, 2 non-locking
- Drawn (seamless) 18 gauge, stainless steel filter pan - 70 lbs. frying compound capacity
- Stainless steel mesh filter screen filters from 2 sides; filter area=270 sq.in.
- 1⁄3 HP motor and pump circulates frying compound at a rate of 8.0 gallons per minute
- One touch push button switch to engage pump and motor
- Tank brush and clean-out rod
- NEMA 5-15P for 120V, 60 Hz, 1 phase
- 6' High temperature discard hose
- One year limited parts & labour warranty
- 10 year fry tank limited warranty
| Product Specifications | |
|---|---|
| Brand | Vulcan |
| Model | 3VK45CF |
| Series | VK |
| Type | Fryers |
| Fuel Type | Natural Gas |
| Capacity | 135-150 lbs |
| Temperature Range | 200 to 390°F |
| Controls | Computer |
| Ignition | Electronic |
| # of Tanks | 3 |
| Tank Size | 14" x 14" |
| Fry Baskets | Twin |
| BTU per Hour | 210,000 |
| Filter Pan Capacity | 70 lbs |
| Filter Area / Fabric Envelope | 270 sq.in. / 350 sq.in. |
| Horsepower | 1/3 |
| RPM | 1750 |
| Pump | 8 Gallons/Minute |
| Electrical | 115V / 60Hz / 1Ph |
| Amps | 7.0 |
| Battery Width | 46.5" |
| Working Height | 36.25" |
| Dimensions - WDH | 46.5" x 30-1⁄8" x 47-1⁄8" |
| Certifications | Energy Star / NSF / CSA |
| Material | Stainless Steel |
| Tank Warranty | 10 Years Limited |
| Warranty | 1 Year |
