Designed for demanding commercial kitchens, this low-profile heavy-duty gas griddle delivers powerful performance in a compact, space-saving footprint. Built with a fully welded stainless steel front, sides, and front top ledge featuring a “Cool Bullnose” design, it combines rugged durability with operator comfort. The body frame is constructed from a blend of stainless and aluminized steel for maximum strength and longevity.
With an 11" low-profile cooking height mounted on 4" adjustable legs, this griddle is ideal for countertop use or under-hood applications where vertical clearance is limited. It features a 1" thick polished steel griddle plate, supported by a 12-gauge, 4" stainless steel back and tapered side splashes for improved cleanliness and splash control. The 3.5" spatula-wide stainless steel grease trough and fully welded grease chute are designed to prevent grease migration and make cleaning fast and easy. A large 6-quart stainless steel grease drawer further enhances convenience during high-volume operation.
Each 12" section of griddle width is powered by a 27,000 BTU/hr “U” shaped aluminized steel burner, delivering even heat across the surface. For precision cooking, each burner is paired with an embedded mechanical snap-action thermostat, allowing temperature adjustments from 200°F to 550°F. Heavy-duty chrome knob guards offer added protection and durability in busy kitchen environments.
Safety features include one pilot safety valve for every two burners, which automatically shuts off gas to both the pilot and burners if the pilot is extinguished. A manual ignition system and bottom heat shields are also included, along with a manual shut-off valve for added control. The unit connects via a ¾" rear gas connection and includes a gas pressure regulator for reliable operation.
This griddle runs on a single gas source with no electrical power required and is backed by a one-year limited parts and labor warranty, making it a dependable, efficient solution for high-performance commercial cooking.
- Stainless steel front, sides and front top ledge with “Cool Bullnose” design
- Fully welded stainless and aluminized steel chassis frame
- 11" low profile cooking height on 4" adjustable legs
- 1" thick polished steel griddle plate with 12 gage, 4" stainless steel back and tapered side splashes
- Spatula-wide 3.5" grease gutter and chute is fully welded for easier cleaning and to stop grease migration
- One 27,000 BTU/hr. “U” shaped aluminized steel burner for every 12" of griddle width
- One embedded snap action thermostat per burner with temperature adjust from 200°F to 550°F
- Large 6 quart stainless steel grease drawer
- Heavy duty chromed thermostat knob guards
- One pilot safety valve for every two burners; safety will completely shut off gas to pilot and burners if pilot extinguishes
- Manual ignition
- Bottom heat shields
- ¾" rear gas connection and gas pressure regulator
- One year limited parts and labour warranty
| Product Specifications | |
|---|---|
| Brand | Vulcan |
| Model | MSA24 |
| Series | MSA |
| Type | Griddles |
| Fuel Type | Natural Gas |
| Total BTU/Hr | 54,000 |
| Cooking Surface - WxD | 24" x 24" |
| # of Burners | 2 |
| Plate Material | Steel |
| Cooking Height | 11-1/8" |
| # of Drawers | 1 |
| Certifications | NSF / CSA |
| Material | Stainless Steel, Aluminum & Steel |
| Warranty | 1 Year |
