The KM-1340MRJ is capable of producing approximately 1371 lbs of crescent cubed ice. Hoshizaki’s efficient double-sided stainless steel evaporators create the unique crescent shaped ice cubes. It is the purest and hardest ice on the market and is a perfect fit for a wide range of applications.
This Remote-cooled with URC-14F icemaker features a CycleSaver design and includes the EverCheck alert system making the unit energy efficient and simple to maintain.
The KM-1340MRJ requires a single phase, 208-230v/60/1. Must be hardwired at site, no cord/plug included. If neutral is not available transformer kit (HS-5030 - sold separately) is required for electrical connection that is hard-wired at the installation site.
*NOTE: Remote condenser is sold separately. Please consult the Specification Sheet for additional details.
- Up to 1371 lbs of ice produced per 24 hours
- Mount 2 units side-by-side for 2x the ice production
- Produces crescent shaped ice cubes
- Durable stainless steel exterior
- EverCheck alert system
- CycleSaver design
- Protected by H-GUARD Plus Antimicrobial Agent
- R-404A refrigerant
- Clean ice and easy maintenance lead to longer unit life span
- Three Years: Parts & Labour warranty on entire machine
- Five Years: Parts & Labour warranty on evaporator
Safely store up to 500 lbs of ice with this B-500SF 30″ high-capacity ice storage bin! It boasts foamed-in-place polyurethane insulation in all of the bin walls and the bottom of the unit to provide you with maximum ice preservation.
The B-500SF features a durable stainless steel exterior cabinet with a seamless, easy to clean, polyethylene bin liner. This model comes standard with 6″ painted legs and a top-hinged front-opening bin door. 3/4″ FPT drain. The unit is ETL verified, NSF and includes a three year parts & labour warranty.
- Stores up to 500 lbs of ice
- Capacity based on 16.33 cu.ft. x 30lbs/cu.ft average density of ice
- Durable and easy to clean stainless steel exterior
- Polyethylene bin liner for sanitary ice storage
- Foamed-in-place polyurethane insulation
- Protected by H-GUARD Plus Antimicrobial Agent
- For top-mounted ice maker, top kits sold separately (See spec sheet for details)
- Top-hinged front-opening bin door
- Sturdy construction capable of supporting stacked ice machine configurations
- Standard with 6″ Painted Legs
- 3/4″ FPT drain
- Three year warranty
This item is not warehoused by Williams Food Equipment, processing times, delivery times and availability may vary. If this item is required by a certain date, please contact Williams Food Equipment before ordering to ensure delivery times can be met. It may not be possible to cancel this item once ordered and may be non-returnable. If returnable this item may be subject to restocking charges and return delivery fees outside of the control of Williams Food Equipment. If you have any questions about this item or the terms above, please call us at 1-888-334-3233 or email us at commercial@williamsfoodequipment.com.
| Product Specifications | |
|---|---|
| Brand | Hoshizaki |
| Phase | 1 Phase |
| Voltage | 208-230 Volts |
| 24 Hour Ice Yield | 1371 lbs. |
| Condenser | Remote |
| Cube Type | Crescent |
| Model | KM-1340MRJ |
| Type | Ice Machines |
| Refrigerant | R-404a |
| Refrigerant Charge Amount | 6 lbs. 9.8 oz. / 11 lbs. 0.4 oz. (with Condenser) |
| Ice Production Air/Water Temp 70°/50°F | 1371 lbs / 24 hr |
| Ice Production Air/Water Temp 90°/70°F | 1177 lbs / 24 hr |
| Water Usage Per 100 lbs | 17.5 Gallons |
| kWh Usage Per 100 lbs | 4.54 |
| Max. Fuse Sz or HACR Circuit Bkr | 20A |
| Amps | 14.0 |
| Heat Rejection BTU/hr | 19,900 |
| Ambient Temp Range | 45 - 100°F |
| Water Temp Range | 45 - 90°F |
| Water Pressure | 10 - 113 PSIG |
| Voltage Range | 187 - 253V |
| Certifications | AQ / KCL / NSF / AHRI / UL / Energy Star |
| Warranty | 3 Years Machine / 5 Years Evaporator / 5 Years Parts Compressor |
| Dimensions - WDH | 30In x 27-3/8In x 41-1/2In |
| Bin Storage Capacity | 500 lbs |
| Liner Material | Polyethylene |
| Model | B-500SF |
| Type | Ice Bins |
| Dimensions - WDH | 30In x 32.3In x 46In |
| Interior Dimensions - WDH | 27In x 27.7In x 37.6In |
| Cubic Volume | 16.33 cu.ft. |
| Warranty | 3 Years |
| Certifications | AQ / KCL / ETL / NSF |
